The fibres are positioned in a loose tube made of PBT. The tube is filled with a water-resistant filling compound. A steel wire locates in the center of core as a metallic strength member. The tubes (and the fillers) are stranded around the strength member into a compact and circular core. The both sides laminated Aluminum tape are longitudinally applied over the cable core, which is filled with filling compound to protect it from water ingress. The cable is completed with a PE sheath.
Characteristics
1.Excellent mechanical and temperature performance.
2.Special tube filling compound ensure a critical protection of fibre and resist the water.
3.Non-metallic central strength member FRP withstand axial loads.
4.100% core filling water prevent cable jelly to ensure the cable watertight.
5.AL tape longitudinal cover cable core as moisture barrier.
6.Outer sheath protects cable from ultraviolet radiation.
Installation: Duct, Non self-supporting aerial.
Applications: Long distance, LAN communication.
Standards: YD/T 901 / IEC 60794-3-10.
Temperature Range
Transportation: -40¡æ~+70¡æ; Installation: -5¡æ~+50¡æ; In use: -40¡æ~+70¡æ.
Technical parameter
Fiber count(core)
2-30
32-36
38-40
42-48
50-60
62-72
74-84
86-96
98-108
110-120
122-132
134-144
Outer diameter£¨mm£©
9.8
10.3
10.4
11.0
11.5
12.2
13.0
14.0
14.8
15.8
16.6
17.4
Cable weigh£¨kg/km£©
90
105
105
125
130
140
155
180
195
220
240
265
Minimum tensile strength£¨N£©
Short-term£º 1500
Long-term£º 600
Minimum crushing (N/100mm£©
Short-term£º 1000
Long-term£º 300
Bending radius
Static£º10 times of diameter Dynamic£º20 times of diameter
Standard length for delivery£¨km£©
2¡«6
Temperature range£¨0C£©
£40¡«£«60
