Single Layer All-Dielectric Self-Supporting ADSS Cable， is designed for outside plant aerial and duct applications in local and campus network loop architectures.The cable  includes fiber counts up to 144 optical fibers and any type of combination of single-mode and laser-optimized multimode fibers with the cable.Pole-to-Pole span lengths range from 50 metres to 300 metres.

Key Features:

1.Suitable for use on distribution and high voltage transmission lines with mini spans or self supporting installation for telecommunication.

2.Small outer diameter and high tensile resistance.

3.High modular of elasticity.

4.Small thermal expansion coefficient.

5.Excellent flexibility capability.

Application: Self-support Aerial installation.

Specification:

Items	Condition	Value
Fiber count	-	2 to 144 core
Max. tensile strength (N)	Short term	As per requested
	Long term	As per requested
Max. crush  strength (N/mm)	Short term	3000 /2200
	Long term	1000
Min. bend radius (mm)	Statics	12.5 * cable diameter
	Dynamics	25 * cable diameter
Drum length (KM)	-	2 to 4
Working temperature (℃)	-	-40 to +60
Contact us for more details

Remarks:

Detail requirements need to be sent to us for cable design and price calculation. Below requirements are a must:

A. Power transmission line voltage level.

B. fiber count.

C. Span or tensile strength.

D. weather conditions.
